Tektronix AWG5200 Series Technical Reference

Brief procedures
Functional test
The purpose of the procedure is to confirm that the instrument functions properly.
The procedures use “AWG” when referring to the AWG5200 series instruments.
The required
equipment is listed below.
Table 36: Required equipment for the functional test
Item Qty. Minimum requirements Recommended equipm ent
Oscilloscope
1 ea.
Bandwidth: 4 GHz or higher
4 c hannels
Tektronix DPO70404C
Function generator 1 ea. 1 kHz, square wave, 5 V
p-p
output
Tektronix AFG3021C
Signal analyzer
1 ea.
Bandwidth: 14 GHz or higher Tektronix RSA5126B
Adapter 4 ea
TekConnect oscilloscope input to SMA input Tektronix TCA-SMA
50 Ω SMA cable
4 ea.
DC to 20 GHz
Tensolite 1-3636-465-5236
50 Ω SMA terminator
3 ea.
DC to 18 GHz
Tektronix part number 136-7162-xx
(supplied with AWG).
50 Ω BNC cable
1 ea. Male connectors both ends Tektronix part number 012-0057-01
SMA-BNC adapter
3 ea.
SMA female to BNC male connector
Tektronix part number 015-0572-00
Planar Crown RF Input
Connector – 7005A-1 SMA
Female
1 ea.
Planar Crown RF Input Connector – Type N
to SMA Female
For use with Tektronix RSA5126B signal
analyzer
Tektronix part number 131-8689-00
Functional c heck
pre
requisites
1. Click the Reset to Default Setup button in the toolbar .
2. Load the test waveform PV_Square.wfmx into the Waveform List.
Test waveforms are located at C:\Program
Files\Tektronix\AWG5200\Samples\PV.
30 AWG5200 Series Technical Reference
