Tektronix AWG5200 Series Technical Reference

Performance tests
Marker high and low level accuracy
Required equipment Prerequisites
Digital multimeter
BNC-dual banana adapter
50 Ω BNC cable
50 Ω BNC feed-through terminator
SMA male-BNC female adapter
50 Ω SMA terminator (three)
(See page 42, Prerequisites.)
Termination resistance measurement
procedure
Marker high level accuracy
Before s
tarting this procedure, ensure you have the “Term R” value used in the
calculations. (See page 44, Termination resistance measurement.)
1. Click the Reset to Default Setup button in the toolbar
.
2. Load the test waveform PV_DC_Plus.wfmx into the Waveform List.
NOTE. Test waveforms are located at
C:\Program Files\Tektronix\AW G5200\Samples\PV.
3. From the Waveform List window, assign the waveform PV_DC_Plus.wfmx
to Channel 1.
4. Press the AWG front panel All Outputs Off button (or click All Outputs Off
on the Home screen) to disable the outputs (front panel light on).
5. Connect the AWG’s CH1:1 marker connector to the HI and LO inputs on the
digital multimeter. Use a 5 0 Ω SMA cable, a BNC-SMA adapter, a 50 Ω BNC
feed-through terminator, and a BNC-Banana adapter.
6. Terminate the AWG’s CH1:2 through CH1:4 markers using 50 Ω SMA
terminators.
58 AWG5200 Series Technical Reference
