Tektronix AWG5200 Series Technical Reference

Specifications
Table 17: SFDR o
perating at 10 GS/s (AC Direct Out)
(–5.0 dBm. Harmonics not included. Measured at the maximum output amplitude.)
10 GS/s In band performance Adjacent band performance
Analog chann
el
output frequency
Measured acr
oss
Specification
Measured acr
oss
Specification
100 MHz 10 to <1250 M
Hz
–80 dBc 1250 to <500
0MHz
–64 dBc
10 to <625 MHz 10 to <1250 MHz –78 dBc 1250 to <5000 MHz –59 dBc
625 to <1250 MHz 10 to <1250 MHz –71 dBc 1250 to <5000 MHz –57 dBc
1250 to <20
00 MHz
1250 to <20
00 MHz
–67 dBc 10 to <1250
MHz
–60 dBc
2000 to <3500 MHz 2000 to <3500 MHz –52 dBc 2000 to <5000 MHz –55 dBc
10 to <2000 MHz –48 dBc
3500 to <5
000 MHz
–56 dBc
10 to <3500 MHz –41 dBc
3500 to <4000 MHz 3500 to <4000 MHz –55 dBc
4000 to <5000 MHz –58 dBc
Table 18: Phase noise operating at 2.5 GS/s
Analog output frequenc y
Offset frequency 100 MHz 1 GHz
100 Hz
–112 dBc/Hz –92 dB c/Hz
1kHz
–132 dBc/Hz –110 dBc/Hz
10 kHz
–136 dBc/Hz –117 dBc/Hz
100 kHz
–134 dBc/Hz –114 dBc/Hz
1MHz
–144 dBc/Hz –124 dBc/Hz
10 MHz
–160 dBc/Hz –150 dBc/Hz
Table 19: Phase noise operating at 5.0 GS/s or 10 GS/s with DDR enabled
Analog output frequency
Offset 100 MHz 1 GHz 2 GHz 4 GHz
100 Hz
–112 dBc/Hz –92 dBc/Hz –86 dBc/Hz –80 dBc/Hz
1kHz
–132 dBc/Hz –110 dBc/Hz –105 dBc/Hz –99 dBc/Hz
10 kHz
–138 dBc/Hz –118 dBc/Hz –112 dBc/Hz –106 dBc/Hz
100 kHz
–138 dBc/Hz –118 dBc/Hz –112 dBc/Hz –106 dBc/Hz
1MHz
–148 dBc/Hz –128 dBc/Hz –122 dBc/Hz –116 dBc/Hz
10 MHz
–160 dBc/Hz –150 dBc/Hz –140 dBc/Hz –140 dBc/Hz
Table 20: Marker outputs
Characteristics Description
Connector type SMA on rear panel.
Number of outputs
4 per channel.
AWG5200 Series Technical Reference 15
