Tektronix AWG5200 Series Technical Reference

Specifications
Table 20: Marker outputs (cont.)
Characteristics Description
Type of output Single ended.
ON/OFF Control Independent control for each marker.
Output impedance 50 Ω
Output voltage Independent control for each marker.
Output voltage into RLOAD [Ω] to G ND is approximately (2 * RLOAD / (50 + RLOAD) ) times of
voltage setting.
Amplitude range
0.2 V
p-p
to 1.75 V
p-p
into 50 Ω.
Window
–0.5 V to 1.7 V into 50 Ω.
Resolution 0.1 mV
External termination voltage –1.0 V to +3.5 V.
Maximum output current 60 mA
DC accuracy (warranted)
±(10% of |output high or low setting| + 25 m V) into 50 Ω.
Rise/fall time < 150 ps (20% to 80% of swing when High = 0.4 V, Low = –0.4 V).
Aberrations
< 20%
p-p
for the first 1 ns following the step transition with 100% reference at 10 ns.
Random jitter
5ps
Sample rate 2.5 GS/s to 5 GS/s.
Min
imum pulse width
400
ps
2 Samples at 5 GS/s.
Ma
ximum data rate
2.5 Gb/s.
Minimum pulse width does not support data output at maximum sample rate.
Skew between markers
(
From the same channel)
±25 ps
Variable delay control
I
ndependent control for each marker.
Range ±2 ns
Resolution 1 ps
Accuracy
±25 ps from delay value.
Table 21: 10 MHz Ref Out (reference output)
Characteristics Description
Connector type SMA on rear panel.
Output impedance 50 Ω (AC coupled).
Amplitude
+4 dBm, ±2 dBm. Sine wave output.
Frequency (warranted)
Within ±(1 ppm + Aging), Aging: ±1 ppm per year.
(Temperature between 0 °C to 50 °C.)
16 AWG5200 Series Technical Reference
