Performance tests
Performance t
ests
This section
contains performance verifi cation procedures for the specifications
listed b elow.
10 MHz reference frequency accuracy
Analog amplitude accuracy
Marker high and low level accuracy
Prerequisites
The tests in this section provide confirmation of performance and functionality
The following requirements and c onditions must be met:
The cabinet must be installed.
The AWG must have been last adjusted at an ambient temperature between
+20 °C and +30 ° C, must have been operating for a warm-up period of at
least 20 minutes, and must be operating at an ambient temperatures between
+10 °C and +40 °C.
You must have performed and passed the procedure Diagnostics and
Calibration, and the procedure Functional Tests.
Required equipment
The following table lists the test equipment required to perform the performance
verification procedures. The table identifies examples of recommended equipment
and lists the required p recision where applicable. If you substitute other test
equipment for the listed examples, the equipment must meet or exceed the listed
tolerances.
Table 37: Required equipment for performance tests
Item Qty. Minimum requirements Recommended equipm ent
Frequency counter 1 ea. Frequency accuracy: within ± 0.01 ppm
Tektronix MCA3040
Digital multimeter 1 ea.
DC accuracy: within ± 0.01%
Keithley 2000 DMM or
Tektronix DMM4040/4050
Adapter 3 ea.
TekConnect oscilloscope input to SMA input Tektronix TCA-SMA
50 Ω SMA cable
1 ea.
DC to 20 GHz
Tensolite 1-3636-465-5236
50 Ω SMA terminator
3 ea.
DC to 18 GHz
Tektronix part number 136-7162-xx
(supplied with AWG).
50 Ω BNC feed-through
terminator
1 ea.
DC to 1 GHz, feedthrough
Tektronix part number 011-0049-02
42 AWG5200 Series Technical Reference
