Tektronix AWG5200 Series Technical Reference

Performance tests
Performance Test Minimum Test result Maximum
Amplitude
10 mV
p-p
9.5 mV 10.5 mV
100 mV
p-p
98 mV 102 mV
500 mV
p-p
480 mV 520 mV
Ch7+
5V
p-p
4.92 V 5.08 V
Amplitude
10 mV
p-p
9.5 mV 10.5 mV
100 mV
p-p
98 mV 102 mV
500 mV
p-p
480 mV 520 mV
Ch8+
5V
p-p
4.92 V 5.08 V
AWG5202,
AWG5204, AWG5208
Amplitude
10 mV
p-p
9.5 mV 10.5 mV
100 mV
p-p
98 mV 102 mV
500 mV
p-p
480 mV 520 mV
Ch1–
5V
p-p
4.92 V 5.08 V
Amplit
ude
10 mV
p-p
9.5 mV 10.5 mV
100 mV
p-p
98 mV 102 mV
500 mV
p-p
480 mV 520 mV
Ch2–
5V
p-p
4.92 V 5.08 V
AWG5204, AWG5208
Amplitude
10 m
V
p-p
9.5
mV
10.
5mV
100 mV
p-p
98 mV 102 mV
500 mV
p-p
480 mV 520 mV
Ch3–
5V
p-p
4.
92 V
5.
08 V
Amplitude
10 mV
p-p
9.5 mV 10.5 mV
1
00 mV
p-p
9
8mV
1
02 mV
500 mV
p-p
480 mV 520 mV
Ch
4–
5V
p-p
4.92 V 5.08 V
AWG5208
Amplitude
10 mV
p-p
9.5 mV 10.5 mV
100 mV
p-p
98 mV 102 mV
500 mV
p-p
480 mV 520 mV
Ch5–
5V
p-p
4.92 V 5.08 V
AWG5200 Series Technical Reference 69
