Tektronix AWG5200 Series Technical Reference

Performance tests
Performance Test Minimum Test result Maximum
Analog Offset Accuracy
(DC High BW Output Path)
AWG5202, AWG5204, AWG5208
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch1+
–2 V –2.05 V –1.95 V
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch2+
–2 V –2.05 V –1.95 V
AWG5204, AWG5208
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch3+
–2 V –2.05 V –1.95 V
Offset
2 V 1.95 V 2.05 V
0 V –10 m
V
10 mV
Ch4+
–2 V –2.05 V –1.95 V
AWG5208
Offset
2 V 1.95 V 2.05 V
0V –1
0mV
10
mV
Ch5+
–2 V –2.05 V –1.95 V
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch6+
–2 V –2.05 V –1.95 V
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch7+
–2 V –2.05 V –1.95 V
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch8+
–2 V –2.05 V –1.95 V
AWG5200 Series Technical Reference 71
