Tektronix DPO2000 Series User Manual

Acquire the Signal
2. Push Average.
Average
Off
Record
Length
100k
Delay
On |
Off
Set Horiz.
Position to
10%
Waveform
Display
XY Display
Off
Acquisition
Details
Average
3. Set the Average acquisition mode from the
side-bezel menu. Yo u ca n chose h ow many
samples on which to average: 2, 4, 8, 16, 32,
64, 128, 256, or 512.
Average
On |Off
4. Turn multipurpose knob a to set the numbe r of
waveforms to average over.
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 89
