Tektronix DPO2000 Series User Manual

Display Waveform Data
2. Turn multipurpose knob a to adjust the vertical
position of the selected bus.
To label a bus, follow these steps:
1. Push the appropriate front-panel bus button.
2. Push Label. (See page 77, Labeling Channels
and Buses.)
Bus (B1)
Parallel
Define
Inputs
Thresholds
(B1) Label
Parallel
Bus Display Event Table
DPO2000 and MSO2000 Series Oscilloscopes User Man ual 163
