Display Waveform Data
2. To change the scale (height) of the digital
channels, push the lower-menu Height button.
D15–D0
On/Off
Thresholds Edit Labels Height
S |ML
NOTE. The S (Small) selection will display
each waveform at 0.2 divisions tall. The M
(Medium) selection will display each waveform
at 0.5 divisions tall. The L (Large) s election will
display each waveform at 1 division tall. L only
works if there is enough room in the display to
display the waveforms. You can display up to 8 L
waveforms at one time.
3. You can label individual digital channels for
easier identification. (See page 77, Labeling
Channels and Buses .)
168 DPO2000 and MSO2000 S eries Oscilloscopes User Manual
