Display a wavefo
rm
Display a wave
form
This section contains concepts and procedures for displaying a waveform. Detailed information is available in the online help.
Setting the Display Style
To set the display s tyle select Display >
Display Style, and then select one of the
following styles:
Displays waveforms with
lines drawn between
record points.
Displays waveform
record points as dots on
the screen.
Displays the actual
samples. Interpolated
points a
re not displayed.
88 MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO /DP O5000 Series U ser Manual
