Tektronix DSA70000D Series User Manual

Appendix D
Specifications
Table 4: Electrical and mechanical specifications
Characteristic Description
Input channels 16 digital
Input resist
ance
100 kΩ ±1.0%
Input capac
itance
3.0 pF
Input signal swing
Minimum 400 mV p-p
Maximum
30Vp-p,≤200 MHz (centered around the DC threshold voltage) at the
probe tip
10Vp-p,≥
200 MHz (centered around the DC threshold voltage) at the
probe tip
Maximum n
ondest–
ructive input signal
±42 V
User defined threshold range
±40 V
Minimum
detectable pulse width
1ns
Digital channel-to-
digita
l channel skew
200 ps
Probe length
1.0 m (3
.28 ft)
Table
5: Environmental specifications
Characteristic Description
Temp
erature
Ope
rating
0°C
to+50°C(+32°Fto+122°F)
Nonoperating
–55
°C to +75 °C (–67 °F to +167 °F)
Humidity
Operating 5% to 95% relative humidity
Nonoperating
10% to 95% relative humidity
Altitude
Operating 4.6 km (15,092 ft) maximum
Nonoperating
15 km (50,000 ft) maximum
Equipment Recycling. This product complies with the European Union’s requirements according to Directive
2002/96/EC on waste electrical and electronic equipment (WEEE). For more information about recycling
options, check the Support/Service section of the Tektronix Web site (www.tektronix.com).
MSO/DPO70000DX, MSO/DPO70000C, DP O7000C, and MS O/DPO5000 Series U ser M anual 187
