Install your ins
trument
5. Verify the ope
rating humidity:
High: 40 °C to 5
0 °C (104 °F to 122 °F), 10% to 60% relative humidity
Low: 0 °C to 40 °C (32 °F to 104 °F), 10% to 90% relative humidity
6. Verify the operating altitude: 3,000 m (9,843 feet)
7. Maximum inpu
t voltage:
50 Ω input imp
edance
1MΩ input impedance
5V
RMS
,withp
eaks ≤±20 V (DF ≤6.25%).
300 V
RMS
, CAT II, with peaks ≤±425 V at the BNC.
For <100 mV/div derate at 20 dB/decade above 100 kHz to 30 V
RMS
at
1 MHz, 10 dB/
decade above 1 MHz.
For ≥100 mV/div derate at 20 dB/decade above 3 MHz to 30 V
RMS
at
30 MHz, 10 dB/decade above 30 MHz.
Maximum nondestructive input voltage to
logic probes:
±42 V
CAUTION. For proper cooling, keep the back and left side of the instrument clear of obstructions.
MSO/DPO70000DX, MSO/DPO70000C, DP O7000C, and MS O/DPO5000 Series U ser M anual 5
