Using the touchscreen interface for common tasks
Use standard touchscreen actions, similar to those found on smart phones and tablets, to interact with most screen objects. You
can also use a mouse to interact with the UI. The equivalent mouse operation is shown for each touch operation.
See the table to quickly learn the fundamental touch operations.
Table 3: Common touchscreen UI tasks (with mouse equivalents)
Task Touchscreen UI action Mouse action
Add a channel, math, reference, or bus
waveform to the screen.
Tap an inactive channel button or the
Add Math Ref Bus button and select a
math, reference, or bus.
Click an inactive channel button or the
Add Math Ref Bus button and select a
math, reference, or bus.
Select a channel, math, reference, or bus
waveform to make it active.
Tap the Channel or Waveform badge or
waveform handle.
Click the Channel or Waveform badge or
waveform handle.
Display scale or navigation buttons on a
badge (waveform, measurement
1
,
search, horizontal).
Tap the badge. Click the badge.
Open a configuration menu on any item
(all badges, views, cursor readouts,
labels, and so on).
Double-tap the badge, view, or other
object.
Double-click the badge, view, or other
object.
Open a right-click menu (badges, views). Touch and hold on the badge, Waveform
View, or other screen item until a menu
opens.
Right-click the object.
Close a configuration menu
2
. Tap anywhere outside the menu or
dialog.
Click anywhere outside the menu or
dialog.
Move a menu. Touch and hold the menu title bar or a
blank area in the menu, then drag the
menu to new position.
Click and hold the left mouse button on
title or blank area and then drag to new
position.
Change horizontal or vertical settings
directly on a waveform.
Vertical changes only apply to the
selected channel or waveform; horizontal
changes apply to all channels and
waveforms.
Tap a badge and use the Scale buttons.
Or, use pinch/expand gestures.
Click a channel, waveform, or Horizontal
badge and click on the Scale buttons.
Increase or decrease the zoom area
(while in Zoom mode).
Touch and hold two fingertips on the
waveform view, move them together or
apart vertically or horizontally, lift from
screen, and repeat.
Click the + or - buttons on the Zoom Title
bar.
Quickly scroll or pan a waveform. Touch and drag in the waveform. Click and drag in the waveform or list.
Close or open the Results Bar to
increase the Waveform View area.
Tap on the Results Bar Handle or
anywhere in the border between the
Waveform View and the Results Bar.
Click the Results Bar Handle or
anywhere in the border between the
Waveform View and the Results Bar.
Click and drag the Results Bar divider.
1
Not all measurement or search badges display navigation buttons.
2
Some dialog boxes will not close until you click an OK, Close, or other button in the dialog.
Getting acquainted with your instrument
MDO32, MDO34 Installation and Safety Manual 29
