Tektronix MDO32 Installation And Safety Manual

Getting acquainted with your instrument
The following content provides a high-level description of the instrument controls and user interface.
Refer to the instrument help for detailed information on using the controls and user interface to display waveforms and take
measurements.
Front panel controls and connectors
The front panel controls provide direct access to key instrument settings such as vertical, horizontal, trigger, and cursors. The
connectors are where you input signals with probes or cables or insert USB devices.
Figure 3: 3 Series MDO controls
MDO32, MDO34 Installation and Safety Manual 9
