Tektronix MSO4000B Series Technical Reference

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
Number of Waveforms
for Average
Acquisition Mode
2to512waveforms
Default of 16 waveforms
Measurement type
DC Ac curacy (in Volts)
Average of  16 waveforms ±[DC Gain Accuracy × | reading – (offset -
position) | + offset accuracy + 0.1 division ]
Refer to D C Gain Accuracy for temperature
derating information.
Delta Volts between any two averages of 16
waveforms acquired with the same oscilloscope
setup and ambient conditions
±[DC gain accuracy × | reading | + 0.05 div]
Refer to D C Gain Accuracy for temperature
derating information.
DC voltage
measurement
accuracy
Average acquisition
mode
Offset, position, and the constant offset term must be converted to volts by multiplying by the appropriate
volts/div term.
The basic accuracy specification applies directly to any sample and to the following measurements: High,
Low, Max, Min, M ean, Cycle Mean, RMS, and Cycle RMS. The delta volt accuracy specification applies to
subtractive calculations involving two of these m easurements.
The delta volts (difference voltage) accuracy specification applies directly to the following measurements:
Positive Overshoot, Negative O ve rshoot, Pk-Pk, and Amplitude.
Measurement type
DC Accuracy (in volts)
Any sample
±[DC gain accuracy × | reading – (offset –
position) | + Offset Accuracy + 0.15 div + 0.6 mV]
Refer to D C Gain Accuracy for temperature
derating information.
Delta volts between any two samples acquired
with the same oscilloscope setup and ambient
conditions
±[DC gain accuracy × | reading | + 0.15 div +
1.2 mV]
Refer to D C Gain Accuracy for temperature
derating information.
DC voltage
measurement
accuracy
Sample acquisition
mode, typical
Offset, position, and the constant offset term must be converted to volts by multiplying by the appropriate
volts/div term.
Analog bandwidth
selections
DPO4104X, DPO4054B, DPO4034B: 20 MHz, 250 MHz, and Full
DPO4014B: 20 MHz and Full
4 MSO4000B and DPO4000B Series Specifications and Performance Verifi cation
