Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
These limits are for ambient temperature of 30°C and the bandwidth selection set to FULL. Reduce the
upper bandwidth frequency by 1% for each °C above 30°C
Instrument
Volts/Div setting
Bandwidth
5 mV/div — 1 V/div DC to 1.00 GHz
2 m V/div — 4.98 mV/div DC to 350 MHz
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
1 m V/div — 1.99 mV/div DC to 175 MHz
5 mV/div — 1 V/div DC to 500 MH z
2 m V/div — 4.98 mV/div DC to 350 MHz
DPO4054B
1 m V/div — 1.99 mV/div DC to 175 MHz
2 mV/div — 1 V/div DC to 350 MH zDPO4034B
1 m V/div — 1.99 mV/div DC to 175 MHz
Analog bandw
idth,
50 , DC coupled
DPO4010B 1 mV/div — 1 V/div DC to 100 MHz
These limits are for ambient temperature of 30°C and the bandwidth selection set to FULL. Reduce the
upper bandwidth frequency by 1% for each °C above 30°C
Instrument
Volts/Div setting
Bandwidth
5 m V/div — 10 V/div DC to 500 MHz
2 m V/div — 4.98 mV/div DC to 350 MHz
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
1 m V/div — 1.99 mV/div DC to 175 MHz
5 m V/div — 10 V/div DC to 500 MHz
2 m V/div — 4.98 mV/div DC to 350 MHz
MSO4054B,
DPO4054B
1 m V/div — 1.99 mV/div DC to 175 MHz
DPO4034B 5 m V/div — 10 V/div DC to 350 MHz
2 m V/div — 4.98 mV/div DC to 175 MHz
1 m V/div — 1.99 mV/div DC to 175 MHz
DPO4014B 1 m V/div — 1.99 mV/div DC to 100 MHz
Analog bandwidth,
1M, DC coupled,
typical
The D PO 4104B, MSO4104B-L, DPO4104B-L, MSO4102B-L, DPO4102B-L, MSO4102B, and DP O4102B
models have separate 50 and 1 M analog paths, so the 1 M path is not checked when the 50 path
is checked in the performance test procedure. All other models have only one analog path, so they are
fully tested with the 50 termination.
MSO4000B and DPO4000B Series Specifications and Performance Verification 5
