Specifications (MSO/DPO5000 Series)
Table 2-1: Analog channel input and vertical specification (cont.)
Delay between
channels, full
bandwidth,
typical
≤100 ps between any two channels w ith input impedance set to 50 Ω, D C coupling, with equal volts/division
setting or above 1 0 mV/div
All settings in the instrument can be manually time aligned using the Probe Deskew function from –125 ns to
+125 ns with a resolution of 20 ps
Deskew range
–125 ns to +125 ns with a resolution of 20 ps
Crosstalk
(channel
isolation), typical
≥100:1 at ≤100 MHz and ≥30:1 at >100 MHz up to the rated bandwidth for any two channels having equal
Volts/Div settings
TekVP I Interface The probe interface allows i nstalling, powering, compensating, and controlling a wide range of probes offering a
variety of features.
The interface is available on all front panel inputs including Aux In. Aux In only provides 1 MΩ input impedance
and does not offer 50 Ω as the other input channels do.
Total probe
power
Five TekVPI-compliant probe interfaces (one per channel)
12 W maximum internal probe power
Provision for 50 W external probe power from rear panel
Voltage Max Amperage Voltage Tolerance
5V
50 mA (250 mW) ±5%
Probe power per
channel
12 V
2 A (24 W) ±10%
