Tektronix MSO70000 Series

Performance Verification (MSO/DPO5000 Series)
Test Record
Model Serial Procedure performed by Date
Test Passed Failed
Self Test
Input Impedance
Performance checks Ve rtical scale Low limit Test result High limit
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
Channel 1 Input
Impedance, 1 MΩ
1 V/div 990 kΩ 1.01 MΩ
10 mV/div 49.5 Ω 50.5 ΩChannel 1 Input
Impedance, 50 Ω
100 mV/div 49.5 Ω 50.5 Ω
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
Channel 2 Input
Impedance, 1 MΩ
1 V/div 990 kΩ 1.01 MΩ
10 mV/div 49.5 Ω 50.5 ΩChannel 2 Input
Impedance, 50 Ω
100 mV/div 49.5 Ω 50.5 Ω
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
Channel 3 Input
Impedance, 1 MΩ
1 V/div 990 kΩ 1.01 MΩ
10 mV/div 49.5 Ω 50.5 ΩChannel 3 Input
Impedance, 50 Ω
100 mV/div 49.5 Ω 50.5 Ω
10 mV/div 990 kΩ 1.01 MΩ
100 mV/div 990 kΩ 1.01 MΩ
Channel 4 Input
Impedance, 1 MΩ
1 V/div 990 kΩ 1.01 MΩ
10 mV/div 49.5 Ω 50.5 ΩChannel 4, Input
Impedance, 50 Ω
100 mV/div 49.5 Ω 50.5 Ω
AUX In Input
Impedance, 250 kΩ
100 mV/div 246 kΩ 254 kΩ
