P6021 Instruction Manual
7
Service Information
Warranted Characteristics
This section lists the various warranted characteristics that describe the P6021
Current Probe. Included are warranted electrical and environmental characteris-
tics.
Warranted characteristics are described in terms of quantifiable performance
limits which are warranted.
The electrical characteristics listed in Table 1 apply under the following
conditions:
H
The probe and instrument must be in an environment whose limits are
described in Table 2.
Table 1: Warranted electrical characteristics
Characteristic Information
Sensitivity 2 mA or 10 mA for each mV at oscilloscope input,
selected by termination sensitivity control
Midband Accuracy ±3% at 10 kHz to 30 kHz
System Bandwidth
(with BW>200 MHz oscilloscope)
2 mA/mV 450 Hz to 60 MHz
10 mA/mV 120 Hz to 60 MHz
Probe Rise Time ≤5.8 ns
Step Response Because the oscilloscope input capacitance becomes
a part of the termination network, the step response
will vary with different oscilloscopes
Aberrations (probe and termination
at either sensitivity setting.)
≤10% peak-to-peak within 50 ns of step; ≤2%
peak-to-peak thereafter
