Service Information
8
P6021 Instruction Manual
Table 2: Warranted environmental characteristics
Characteristic Information
Temperature range
Operating –0 _ C to +50 _ C (+32 _ F to +122 _ F)
Nonoperating –40 _ C to +65 _ C (–40 _ F to +149 _ F)
Altitude
Operating To 2,000 m (6,561 ft), <300 V CAT I
To 4,572 m (15,000 ft), <150 V, CAT I
Nonoperating To 15,240 m (50,000 ft)
Table 3: Maximum ratings
Characteristic Information
Maximum Continuous (CW) Current Refer to Figure 3 for frequency derating curves
2 mA/mV 5A
p-p
sine wave between 1.2 kHz and 5 MHz
10 mA/mV 15 A
p-p
sine wave between 300 Hz and 5 MHz
Maximum Pulse Current 250 A peak, not to exceed 500(A · m s) or 5 A
RMS
. An
(A · s) product greater than 500(A · m s) reduces
probe output to zero due to core saturation
Maximum Working
Input Voltage
(uninsulated conductors)
300 VAC or VDC, CAT I, and 600 V
pk
limited to
<10 ms and <25% duty factor.
