Tektronix P6021 - Figure 3: Probe and Termination Input Current Vs; Table 4: Certifications and Compliances

Service Information
P6021 Instruction Manual
9
100 MHz10 MHz1 MHz1 kHz100 Hz10 Hz
FREQUENCY
1A
0.1A
PĆP
AMPS
10 A
20 A
100 A
10mA/mV
2 mA/mV
Figure 3: Probe and termination input current vs. frequency derating
Table 4: Certifications and compliances
EC Declaration of Conformity – Low Voltage
Compliance was demonstrated to the following specifications as listed in the
Official Journal of the European Communities:
Low Voltage Directive 73/23/EEC, as amended by 93/68/EEC
EN 61010-1/A2 Part 1: General Requirements
Safety requirements for electrical equipment for
measurement, control, and laboratory test
EN 61010-2-032:1995 Part 2-032:
Particular requirements for hand-held current clamps
for electrical measurements and test
Listed UL1244, Third Edition Electrical and electronic measuring and test
equipment
