Specifications
Input frequen
cies ≤ 6.2 GHz
Spurious responses due to the following mechanisms: RFx2*LO1, 2RFx2*LO1,
RFx3*LO1, RFx5*LO1, RF to IF feed-through, IF2 Image.
 –60 dBc
Spurious responses due to First IF images (RFXLO1):
 –60 dBc, < 2700 MHz center frequency
 –50 dBc, 270
0 – 6200 MHz center frequency
Exceptions:
IF feedthrough:  –45 dBc for 1850 MHz – 2700 MHz center frequency, typical
First IF Image:  –55 dBc for 1850 MHz – 1870 MHz center frequency, typical
 –35 dBc for 3700 MHz – 3882 MHz center frequency, typical
 –35 dBc fo
r 5350 MHz – 5700 MHz center frequency, typical
Second IF I
mage:  -50 dBc 22 - 1850 MHz
 -50 dBc 4175-4225 MHz
RFx2LO:  –50 dBc for 4750 MHz – 4810 MHz center frequency, typical
2RFx2LO:  –50 dBc for 3900 MHz – 3940 MHz center frequency, typical
RFx3LO:  –45 dBc for 4175 MHz – 4225 MHz center frequency, typical
Spurious responses due to ADC images:
 –60 dBc, offset from center frequency > 56 MHz
 –50 dBc
,56MHz offset from CF  36 MHz
Input f
requencies > 6.2 GHz – 8.0 GHz (typical)
Spurious responses due to the following mechanisms: First IF Image, RFX2LO1,
2RFX2LO1, RFX3LO 1, RFX5LO1, IF2 Image.
 –60 dB
c
Exceptions:
First IF Image:  –40 dBc for  3800 MHz center frequency, typical
RFx2LO:  –25 dBc for 4800 MHz – 5150 MHz center frequency, typical
 –40 dBc for 5150 MHz – 5800 MHz center frequency, typical
RFx3LO:  –40 dBc for 4150 MHz – 4250 MHz center frequency, typical
