Tektronix RSA306B Technical Reference

Specifications
Interfaces, input, output ports
RF input
Type N, female
External frequency reference
input
SMA, female
Trigger/syn
c input
SMA, female
Status indi
cator
LED, dual co
lor red/green
LED states:
Steady Red: USB power applied, or resetting
Steady G re
en: Initialized, ready for use
Flickering Green: Transferring acquired data to host PC
USB d evice port USB 3.0 - Micro-B (with thumbscrews)
Power
Power consumption
Per USB 3
.0 SuperSpeed requirements: 5.0 V,  900 mA, nominal
Physical
Weight
0.59 kg (1.3 lbs)
Dimensions
Heigh
t
30.5 mm (1.2 in)
Width
127 mm (5.0 in)
Dept
h
190.5 mm (7.5 in)
Reg
ulatory
Saf
ety
UL6
1010-1, CAN/CSA-22.2 N o.61010-1, EN61010-1, IEC61010-1
Re
gional certifications
Europe: EN61326
Au
stralia/New Zealand: AS/NZS 2064
EM
Cemissions
EN61000-3-2, EN61000-3-3, EN61326-2-1
E
MC immunity
E
N61326–1/2, IEC61000-4-2/3/4/5/6/8/11
10 RSA306B Specifications and Performance Verification
