Specifications
Swept and Real time
RF full band sweep time,typical
mean
16.5 GHz/sec (RBW = 1 MHz)
16.5 GHz/sec (
RBW = 100 kHz)
13.7 GHz/sec (RBW = 10 kHz)
1.9 GHz/sec (RBW = 1 kHz)
(Measured us
ing a Panasonic Toughpad FZ-G1, Intel® Core™ i5-5300U 2.3GHz
Processor, 8GB RAM, 256GB SSD, Windows®7 Pro.)
(Spectrum display is only measurement on screen.)
DPX bitmap image resolution 201 pixels vertical x 801 pixels horizontal
DPX spectro
gram minimum time
resolution
1 milliseco
nd
(10,000 spectrums per second)
Due to the non-deterministic execution time of programs running under Microsoft
Windows OS
, this specification may not be met when the host PC is heavily loaded
with other processing tasks
Audio dem
odulation
Types AM, FM
(Audio fil
e output: 16 bits at 32 ksps in .wav format.)
IF bandwidth range Five selections, 8 kHz – 200 kHz
Audio output frequency range
50Hz–10kHz
Minimum signal
durati
on for 100% POI
Test controller
27
Dell De
sktop (Windows® 10 Enterprise, Intel® Core™
i7-4790 CPU, 3.6GHz, 8GB RAM, 256GB SSD)
34
Dell Desktop (Windows® 7 Enterprise, Intel® Core™
i7-2600 CPU, 3.4GHz, 8GB RAM, 256GB SSD)
36
Dell Laptop Latitude E6430 (Windows® 10 Enterprise,
Inte
l® Core™ i7-3520M CPU, 2.9GHz, 8GB RAM,
250 GB SSD)
35
Dell Laptop Precision M4700 (Windows® 8 Enterprise,
Intel® Core™ i7-3520M CPU, 2.9GHz, 8GB RAM,
750
GB HD)
37
Pan
asonic ToughPad SAPL-TP-04 (Windows® 7 Pro,
Intel® Core™ i5-5300U CPU, 2.3GHz, 8GB RAM,
256GB SSD)
DPX settings: Span = 40 MHz, R BW = 300 kHz (Auto)
10,000 per second (span independent)
Minimum
signal duration (100%
POI),typical
Due to the nondeterministic execution time of programs running under Microsoft
W
indows OS, this specification may not be met when the host PC is heavily loaded
with other processing tasks
RSA306B Specifications and Performance Verification 9
