Tektronix RSA306B Technical Reference

Performance ver
ification
Table 2: RSA306B required test equipment (cont.)
Item Description Qty Model Number Purpose
Band pass filter 2150 MHz, SMA
2
Mini-Circuits Labs
ZX75BP-2150+
For third-order distortion
measurement
Low pass filter 5000 MHz cutoff, L250 filter
1
K&L 5L250-5000/E 15000 –
O/OP
Spurious test
Tunable filter
1500 MHz to 3000 MHz, N
connectors
1
K&L 5BT-1500/3000-5-N/N Spurious test
Alternative to tunable
filter
300 MHz lowpass cutoff, L250
filter
1
K&L 5L250-3300/E 10000 -
O/OP
Cable, SMA-to-N ST18/SMAm/Nm/36in
1
Huber-Suhner 84004594 Generator output to RF
input
Cable, SMA ST18/SMAm/SMAm/36in
2
Huber-Suhner 84002061 TOI and tests requiring
low-pass filters
Cable, SMA ST18/SMAm/SMAm/8
2
Huber-Suhner 84028563 TOI tests
Cable, BNC-to-SMA BNC(m) to SMA(m) cable -
1 meter
1 Pasternack PE3615-36
Generator timebase output
to Ref IN.
(External-timebase to
generator-timebase input
may need a similar cable)
Torque wrench 12 in-lb - Type N 1
Maury Microwave 2698C2
N- connector attachments
Torque wrench 8 in-lb Torque wrench - 3.5 mm 1
Huber-Suhner 74Z-0-0-21 SMA-connector
attachments
NOTE. Make sure that any adaptor and cable y ou use is specified to operate at the frequency range of the test you
are performing. Connector frequency ranges:
BNC: D C to 1 GHz typical, up to 3 GHz for certain BNC cable/connectors.
N:DCto18GHztypical
SMA: DC to 18 GHz typical, up to 26.5 GHz for certain SMA cable/connectors.
Preliminary checks
Do these steps before starting the performance verification procedures.
Warm up the instrument
1. Connect the RSA306B USB c able to the host PC. The LED on the RSA306B should initially glow red then turn green
after a few moments.
2. Make sure the SignalVu-PC application is connected to the RSA306B over USB.
14 RSA306B Specifications and Performance Verification
