Tektronix RSA306B Technical Reference

Specifications
Noise and distortion
Displayed average noise level
(DANL) 
Reference level = –50 dBm, input terminated with 50  load, log-average (10 averages)
Center frequency Frequency range
DANL (dBm/Hz),
18 ⁰Cto28⁰C
DANL (dBm/Hz),
–10 ⁰Cto55⁰C,
typical
< 22 MHz (LF path)
100 kHz to
<42MHz
 –130  –133
 22 MHz (RF path)
2MHzto<5MHz  –145  –148
5 MHz to < 1.0 GHz
 –161  –163
1.0 GHz to
<1.5GHz
 –160  –162
1.5 GHz to
<2.5GHz
 –157  –159
2.5 GHz to
<3.5GHz
 –154  –156
3.5 GHz to
<4.5GHz
 –152  –155
4.5 GHz to 6.2 GHz
 –149  –151
Phase noise
Phase Noise (dBc/Hz) measured with 1 GHz CW signal at 0 dBm
Offset: Center frequency, dBc/Hz
1GHz
10 MHz
(typical)
1GHz
(typical)
2.5 GHz
(typical)
6GHz
(typical)
1kHz  –84  –115  –89  –78  –83
10 kHz  –84  –122  –87  –84  –85
100 kHz  –88  –126  –93  –92  –95
1MHz  –118  –127  –120  –114  –110
Residual spurious response,
typical
Reference level  –50 dBm, RF input terminated with 50 
Center frequency
9kHzto<1GHz
< –100 dBm
1to<3GHz
< –95 dBm
3to6.2GHz
< –90 dBm
With the following exceptions:
<–80 dBm, Center Frequency 2080-2120
<–80 dBm, Center Frequency 3895 -3945 MHz
<–85 dBm, Center Frequency 4780-4810 MHz
Input related spurious response
(SFDR) 
Conditions: 18 °C to 28 °C, auto settings on, reference level -30 dBm, input
amplitude at or below reference level.
RSA306B Specifications and Performance Verification 5
