Performance ver
ification
Table 12: 2160 MHz Channel flatness, 2140 MHz – 2180 MHz
Signal
generator
frequency
Power meter
amplitude, dB
RSA306B mar-
ker amplitude,
dB
Difference
amplitude, dB
m
Channel
flatness error,
dB
2140 MHz
2142 MHz
2144 MHz
2146 MHz
2148 MHz
2150 MHz
2152 MHz
2154 MHz
2156 MHz
2158 MHz
2160 MHz
2162 MHz
2164 MHz
2166 MHz
2168 MH
z
2170 MHz
2172 MHz
2174 M
Hz
2176 MHz
2178 MHz
2180
MHz
Maximum difference amplitude
<+1dB
Minimum difference amplitude
>–1
dB
