Performance ver
ification
11. Repeat steps 6 through 10 for each center frequency and signal generator frequency listed in the table. Make sure to set
the signal gene
rator for –30 dBm at the power meter for each frequency change.
12. Record result
s in the Test record.
NOTE. This table includes the worst RF X 2LO spurs observed on the RSA306B.
Table 21: RF X 2LO: RSA306B and signal generator frequencies
Center frequency, MHz
(RSA306B)
Signal generator
frequency, MH z
RF X 2LO spur
amplitude, dBm
RF X 2LO spur
amplitude, dBc
1
Specificati
on, dBc
(relative to –30 dBm
input)
1190 MHz 4820 MHz < –60 dBc
1890 MHz 4970 MHz < –60 dBc
2330 MHz 5850 MHz < –60 dBc
4840 MHz 6110 MHz < –60 dBc
1
RF X 2LO spur amplitude + 30.
48 RSA306B Specifications and Performance Verification
