Performance ver
ification
11. Repeat steps 6 through 10 for each center frequency and signal generator frequency listed in the table. Make sure to set
the signal gene
rator for –30 dBm at the power meter for each frequency change.
12. Record result
s in the Test record.
NOTE. This table includes the worst RF X 3LO spurs observed on the RSA306B.
Table 22: RF X 3LO: RSA306B and signal g enerator frequencies
Center frequency, MHz
(RSA306B)
Signal generator
frequency, MH z
RF X 3LO spur
amplitude, dBm
RF X 3LO spur
amplitude, dBc
1
Specificati
on, dBc
(relative to –30 dBm
input)
130 MHz 5270 MHz < –60 dBc
420 MHz 6140 MHz < –60 dBc
1
RF X 3LO spur amplitude + 30.
