Tektronix RSA306B Technical Reference

Performance ver
ification
Spurious response: Half-IF, 2240 MHz
Center frequency, MHz
Half-IF spurious
amplitude, dBc
Specification
,dBc
(relative to –30 dBm
input) Pass/Fail
30 MHz < –50 dBc
710 MHz < –50 dBc
4200 MHz < –50 dBc
Spurious response: 2RF X 2LO
Center frequency, MHz
Generator
frequency, MHz
2RF X 2LO spur
amplitude, dBc
Specificat
ion, dBc
(relative to –30 dBm
input) Pass/Fail
2190 MHz 2785 MHz < –60 dBc
2870 MHz 4655 MHz < –60 dBc
RSA306B Specifications and Performance Verification 57
