Tektronix TBS2000B Series Service Manual

Fig. &
index
number
Tektronix part number Serial no.
effective
Serial no.
discont'd
Qty
1
Name & description
-7 850-0312-xx 1 FRAME ASSEMBLY; DISPLAY; TBS2K
-8 407-5760-xx 1 BRACKET, DISPLAY MOUNT
-9 441-2848-xx 43
2
CHASSIS, FRONT
-10 211-1272-xx 6 SCREW, MACHINE; 6-32 X 0.250, PNH, STL,
ZNPL,T-15 TORX DR
-11 131-6643-xx 1 CONTACT, ELECTRICAL
12 174-5411-xx 1 CABLE EXTENSION, USB-HOST
-13 174-6623-xx 1 CABLE, DISPLAY, FFC, 50POS
-14 870-1172-xx 1 PCB, FRONT-PANEL
-15 260-3115-xx 1 SWITCH, KEYPAD, ASSEMBLY FRONT
-16 174-6696-xx 1 CABLE CONNECTION, FRONT-PANEL & POWER SWITCH
-17 335-4044-xx 1 MARKER, IDENTIFICATION LABEL, SAFETY
CONTROLLED
335-4155-xx 1 MARKER, IDENTIFICATION FRONT PANEL OVERLAY,
KOREAN
335-4147-xx 1 MARKER, IDENTIFICATION FRONT PANEL OVERLAY,
FRENCH
335-4156-xx 1 MARKER, IDENTIFICATION FRONT PANEL OVERLAY,
RUSSIAN
335-4148-xx 1 MARKER, IDENTIFICATION FRONT PANEL OVERLAY,
ITALIAN
335-4149-xx 1 MARKER, IDENTIFICATION FRONT PANEL OVERLAY,
GERMAN
335-4150-xx 1 MARKER, IDENTIFICATION FRONT PANEL OVERLAY,
SPANISH
335-4151-xx 1 MARKER, IDENTIFICATION FRONT PANEL OVERLAY,
JAPANESE
335-4153-xx 1 MARKER, IDENTIFICATION FRONT PANEL OVERLAY,
SIMPLE CHINESE
335-4154-xx 1 MARKER, IDENTIFICATION FRONT PANEL OVERLAY,
STANDARD CHINESE
-18 366-0935-xx 5 ASSEMBLY, KNOB; .685 DIAMETER
-19 366-0934-xx 6 ASSEMBLY, KNOB; .470 DIAMETER
-20 366-0936-xx 1 ASSEMBLY, KNOB; .925 DIAMETER
-21 335-4113-xx 1 MARKER, IDENTIFICATION LABEL, SAFETY
CONTROLLED
1
Quantity indicated is for the entire instrument, not necessarily for each image.
Replaceable parts
24 TBS2000B Series Service Manual
