Tektronix TDS3000B Series Reference

14
XY Cursor Menu
The following cursor menu items are available in the XY
display mode (DISPLAY > XY Display > Triggered
XY). Push the CURSOR button to show the cursor
menu.
Bottom Side Description
Function
Off Turns cursors off.
Waveform Turns waveform cursors on and
displays measurements in
rectangular format (X and Y
values). Use the front-panel
SELECT button to select a
cursor. Use the general purpose
knob to move the active cursor.
Mode
Independent Sets cursors to move indepen-
dently.
Tracking Sets cursors to move together
when the reference cursor is
selected.
NOTE. The Advanced Analysis application
module (TDS3AAM) adds more XY cursor
features, including graticule cursors and polar
readouts.
13
Bottom DescriptionSide
WaveAlert
(cont.)
Hardcopy
On Anomaly
On Off
When On, the oscilloscope
sends an image of the screen to
the hard copy device or floppy
file if there is a waveform anom-
aly on any channel.
Wfms To Disk
On Anomaly
On Off
When On, the oscilloscope
saves the anomalous wave-
form(s) data to the floppy disk
drive.
Highlight
Entire Wfm
Highlights the entire anomalous
waveform.
Highlight
Anomaly
Highlights just the anomalous
data in a waveform.
WaveAlertt Waveform Anomaly Detection. WaveAlert
provides a way to detect when a waveform deviates from
a steady-state condition. WaveAlert monitors the current
waveform acquisition and compares it to the previous
waveform acquisition. If the current acquisition exceeds
the comparison tolerance, the oscilloscope considers the
current acquisition as an anomaly and responds by
stopping acquisitions, emitting a beep, saving the
anomalous waveform to a disk file, printing the screen
image to a hard copy device, or any combination of the
above. Refer to the TDS3000B Series Digital Phosphor
Oscilloscope User Manual for more information.
