Appendix A: Specifications
Vertical
Minimum width o f pulse with amplitude of ≥2 div to capture
50% or greater amplitude
Sample rates ≤125 MS/s S ample rates ≥250 MS/s
Peak
detect or
Envelope
pulse
response,
typical
1ns
1/sample rate
DC gain
accuracy
± 2%, derated at 0.025%/°C for temp eratures above +30 °C,
in Sample or Average acquisition mode
DC
measurement
accuracy,
Measurement type
DC Accuracy (in volts)
Absolute measurement of
any waveform point
± [0.02
1
× | reading - (offset
- position) | + offset accuracy
+0.15div+0.6mV]
Sample
acquisition
mode,
typical
Delta voltag e between any
two points on a waveform
± [0.02
1
× | reading | +
0.15 div + 1.2 mV]
DC
measurement
accuracy,
Measurement type
DC Accuracy (in volts)
Absolute measurement of
any waveform point
± [0.02
1
× | reading - (offset
- position) | + offset accuracy
+0.1div]
Average
acquisition
mode (≥16
averages)
Delt
a voltag e between any
two
points on a waveform
± [0.02
1
× | reading | +
0.05 div]
Scale range Offset range
1mV/divto9.95mV/div
±100 mV
10 mV/div to 99.5 mV/div
±1 V
100 mV/div to 995 mV/div
±10 V
Offset
range
1 V /div to 10 V/div
±100 V
Offset
Accuracy,
all ranges
± [0.005 | offset - position | +0.1 div]
Note: Convert b oth the constant offset and position terms to
volts by multiplying by the volts/div setting.
1
0.02 term (gain component) derated at 0.0 0025/°C above 30 °C.
TDS3000C Series O scilloscope User Manual 153
