Operating Information
1-16
TDS3000C Series S ervice Manual
12. Auxiliary waveform readouts show the vertical and horizontal scale factors
of the math or reference waveforms.
13. Channel readouts show the channel scale factor, coupling, input resistance,
bandwidth limit, and invert status.
14 15
14. A triangle icon with the battery icon indicates that a battery is installed and
battery power is in use. The battery icon shows the approximate charge level
of the battery. See page 1--3 for important safety information.
15. A power-plug icon with the battery icon indicates that a battery is installed
but line power is in use. The battery may be charging. The battery icon
shows the approximate charge level.
The QuickMenu feature simplifies the use of the oscilloscope. When you push
the QuickMenu button, a set of frequently used menu functions show on the
display. Then, push the screen buttons around the display to operate the
QuickMenu.
Using the Scope QuickMenu. Scope is one type of QuickMenu that you can use to
control the basic oscilloscope functions. You can perform many tasks without
using the regular menu system. If you need to use a function that is not contained
in the Scope QuickMenu, push the button you would normally push to access
that function. For example, if you want to add an automatic measurement, push
the Meas button to set up the measurement. Then, push the QuickMenu button to
return to the Scope QuickMenu with the measurement also in the display.
Using Quick Menus
