Tektronix TDS3032B Service Manual

Mechanical Parts List
10- 4
TDS3000B Series Service Manual
Figures 10--1 through 10--5 on the following pages show the m odule-level
exploded views of the TDS3000B series oscilloscope. The adjacent page is the
list of components for that exploded view, indexed by the numbers in the figure.
1
2
3
4
5
6
7
8
9
10
Figure 10- 1: Exploded view, front case half
Exploded Views
