Tektronix TDS3032B Service Manual

Mechanical Parts List
10- 14
TDS3000B Series Service Manual
Replaceable parts list
Fig. &
index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont’d
Qty Name & description Mfr. code Mfr. part number
10-5-1 367--0498--00 1 HANDLE,CARRYING:14.5740 X 6.3230 7X318 367--0498--00
10-5-2 200--4415--00 1 COVER:OPTION MODULE OPENING,5.1440 X 0.910
X 0.9950,PC/ABS,FR110,BLUE
TK6179 200--4415--00
10-5-3 211--0722--00 1 SCREW,MACHINE:6--32 X
0.250,PNH,STL,CDPL,T--15 TORX DR
0KB01 ORDER BY DESCR
10-5-4 436--0371--00 1 TRAY,ACCESSORY:BATTERY COMPARTMENT TK6179 436--0371--00
10-5-5 200--4394--00 2 COVER,HUB:POLY,1.60 DIAMETER 7X318 200--4394--00
10-5-6 401--0785--00 2 HUB ASSY:NYLON 7X318 401--0785--00
10-5-7 343--1213--00 1 CLAMP,PWR CORD:POLYMIDE TK1163 ORDER BY DESCR
10-5-8 050--3514--XX 1 PARTS REPL KIT:REAR CASE, TDS3000B SERIES 80009 050--3514--XX
10-5-9 348--1582--00 2 FOOT ASSY:FRONT,HINGED,HOUSING
380--1118--00, FRONT FOOT 348--1557--00,
7X318 348--1582--00
Accessories list
Fig. &
index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont’d
Qty Name & description Mfr. code Mfr. part number
200--4416--00 1 COVER:FRONT,PROTECTIVE
(SEE FIGURE 10-1-8)
7X318 200--4416--00
_________ 2 P3010 PASSIVE PROBE, 10X, 100MHZ, W/ACCY
(TDS301xB MODELS ONLY)
ORDER BY DESC
_________ 2 P6139A PASSIVE PROBE, 10X, 300&500MHZ,
W/ACCY (TDS302xB-TDS306xB MODELS ONLY)
ORDER BY DESC
436--0371--00 1 TRAY,ACCESSORY:BATTERY COMPARTMENT TK6179 436--0371--00
020--2382--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT, ENGLISH TK2548 020--2382--XX
020--2383--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT, FRENCH TK2548 020--2383--XX
020--2384--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT, GERMAN TK2548 020--2384--XX
020--2385--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT, ITALIAN TK2548 020--2385--XX
020--2386--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT, SPANISH TK2548 020--2386--XX
020--2387--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT,
PORTUGUESE
TK2548 020--2387--XX
020--2388--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT, KOREAN TK2548 020--2388--XX
020--2389--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT,
SIMPLIFIED CHINESE
TK2548 020--2389--XX
020--2390--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT,
TRADITIONAL CHINESE
TK2548 020--2390--XX
020--2391--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT,
JAPANESE
TK2548 020--2391--XX
020--2392--XX 1 MANUAL SET; TDS3000B DOCUMENT KIT, RUSSIAN TK2548 020--2392--XX
071--0972--XX 1 MANUAL,TECH: SERVICE,TDS3000B SERIES TK2548 071--0972--XX
