Getting Started
5. Channel vertical controls. Push these screen buttons to set vertical
controls for the selected channel. Use the channel 1, 2, 3, 4, and the
Math and Ref buttons to select th e channel you want to contro l.
6. Vertical controls if either the m ath waveform or a reference
waveform is selected.
7. Menu. Push this screen button to select a specific QuickMenu
display if more than one is available.
NOTE. Items in the Scope QuickMenu not mentioned above are also
contained in the regular display. (See pa ge 23.)
Other Q uickMenus. Some optio nal application packages include a
custom QuickMenu display. T h ose QuickMenus contain specific
features that are impo
rtant for the application.
TDS3000C Series O scilloscope User Manual 27
