Tektronix TDS3032C Service Manual

TDS3000C Series S ervice Manual
3-1
Adjustment Procedures
This chapter contains the factory adjustment procedures for the TDS3000C series
oscilloscopes. Only qualified personnel should perform adjustment procedures.
Read the Service Safety Summary and the General Safety Summary before
performing any service procedures. Also refer to the chapter Operating
Information for information about using the oscilloscope.
NOTE. The voltage references inside the oscilloscope are very stable over time
and should not require routine adjustment. Before performing any procedure in
this chapter, do the Performance Verification procedures (found in the Specifica-
tions and Performance Verification technical reference, available on the Web at
www.tektronix.com/manuals) to check whether or not the oscilloscope meets
specifications.
Successful completion of this adjustment procedure automatically updates the
instrument Calibration Due date and time. Successful completion of the
Performance Verification procedure does not update the instrument Calibration
Due date and time.
Required Equipment
The following equipment, or a suitable equivalent, is required to complete these
procedures.
Description
Minimum
requirements
Example
DC voltage source 50 mV to 70 V, ±0.1% amplitude
accuracy
Wavetek 9500 Oscilloscope
Calibrator with one 9510
O
u
t
p
u
t
M
o
d
u
l
e
Leveled sine wave generator 30 kHz to 80 MHz, 100 ppm
frequency accuracy, 3% ampli-
tude accuracy
Output Module
Fast-rise generator 100 Hz - 1 MHz repetition rate,
2.2 V Pk-Pk signal (--2.2 V to
0 V) unloaded signal, ≤1nsrise
time
50 Ω BNC cable
(five required
1
)
BNCmaletoBNCmale,≈ 10 in
(25 cm.) long
Tektronix part number
012-0208-00
BNC T (three required
1
) One male and two female BNC
connectors
Tektronix part number
103-0030-00
