Reference
Acquire Menu
Push the Acq uire Menu button to show the Acquire menu.
Bottom Side Description
Sample Use for normal acquisition.
Peak Detect Detects glitches and reduces the
possibility o f aliasing.
Envelope N
Captures variations of a signal over
a period of time. (Adjust N with the
general purpose knob.)
Mode
Average N Reduces random or uncorrelated
noise in the signal display. (Adjust N
with the general purpose knob.)
Fast Trigger (500
points)
Acquires 500 point waveforms at a
fast repetition rate.
Horizontal
Resolution
Normal (10k points) Acquires 10,000 point waveforms
with more horizontal detail.
Reset
Horizontal
Delay
Set to 0 s
Resets the horizontal delay time to
zero.
Normal A utoset
Execut
es the autoset function.
(Opti
onal application modules may
add ch
oices to execute specialized
auto
set functions.)
Autoset
Undo Autoset
Reverts to the settings before the
last autoset.
62 TDS3000C Series Oscilloscope User Manual
