TDS5000B Series (Option 1R) Rackmount Kit

Kit Description

This introduction describes the installation of the rackmount kit to your standard

bench-top instrument.

The rackmount kit is a collection of parts that, once installed, configure the

instrument for mounting into a standard 19-inch equipment rack.

Products

TDS5000B Series AllSerialNumbers

Kit Parts List

Figure 1

on page 4

Quantity Part number Description

-- -- -- -- -- -- -- -- -- 1ea 016-1887-XX RACKMOUNT KIT TDS5000B SERIES CON-

SISTING OF THE FOLLOWING:

-- -- -- -- -- -- -- -- -- 1 e a 071-1421-01 TECH MANUAL: INSTRUCTIONS, TDS5000B

SERIES

1-1 1 ea 386-7301-00 RACKMOUNT PANEL LEFT

1-2 1 ea 386-7302-00 RACKMOUNT PANEL RIGHT

1-3 4 ea NS SCREW, MACH: 10-32, PAN-HEAD, 0.5 IN I,

PHILLIPS

1-3 7 ea NS NUT, LOCKING WASHER: 10-32 ASSEM

1-3 20 ea NS SCREW, MACH: 10-32, TRUSS-HEAD, 0. 375 IN

I, PHILLI PS

1-3 4 ea NS SCREW, MACH: M6 x 20 OVAL-HEAD,

PHILLIPS

1-3 4 ea NS SCREW, MACH: M5 x 20 OVAL-HEAD,

PHILLIPS

1-3 4 ea NS SCREW, MACH: 10-32 x 0.75 OVAL-HEAD,

PHILLIPS

1-3 4 ea NS SCREW, MACH: 12-32 x 0.75 OVAL-HEAD,

PHILLIPS

1-3 5 ea NS WASHER: FLAT, NYLON

1-4 2 ea 351-1095-00 SLIDE, DRAWER, EXTENDERS: SLIDERS

1-4 2 ea NS RACK: MOUNTING SCREWS, NUT BLOCKS

1-5 1 ea 200-4866-00 COSMETIC COVER, RACKMOUNT

1-6 1ea 386-7340-00 PLATE: SHEET METAL, GUARD BRACKET
