TDS5000B Series (Option 1R) Rackmount Kit
9
Installation Instructions
This section contains all procedures needed to rackmount the TDS5000B.
Minimum Tool and Equipment List
The following tools are required to attach the rack-adapter kit hardware, install
cabling hardware, and mount the rack-adapted instrument into a standard
equipment cabinet. All tools are standard tools that are readily available.
Table 2: Tools required for rackmount installation
Item
no.
Name Description
1 Screwdriver handle
(magnetic )
Accepts 1/4-inch hexagonal head driver tips
2 No. 2 Phillips or
PoziDriv tip
Phillips or PoziDriv-driver tip f or number 2 size screw heads
3 T-15 T orx tip Torx-driver tip for T-15 size screw heads
4 1/4-inch wrench Wrench or nut driver can be used to instal l slides
5 Torque driver Accepts 1/4-inch hexagonal head driver tips
6 1/8 inch flat-bladed
screwdriver
Screwdriver can be used t o remove the CD drive trim
These instructions are for qualified service personnel who are familiar with
servicing the product. If you need further details for disassembling or reassem-
bling the product, refer to the appropriate product manual. Contact your nearest
Tektronix Service Center or Tektronix Factory Service for installation assistance.
WARNING. To prevent the rackmounted instrument from tipping forward onto the
operator, install the instrument so that the operator will be able to access all of
its rear-panel connectors without pushing down on the instrument.
Verify that the rack does not become unstable with the instrument fully extended.
Do not leave the instrument extended when finished accessing the rear panel.
