Installation Instructions
16
TDS5000B Series (Option 1R) Rackmount Kit
Rackmount the Rack-Adapted Instrument
This procedure assembles and installs the slide-out tracks in the equipment rack,
and then installs the rack-adapted instrument in the rack.
The slide-out tracks permit the rack-adapted instrument to be extended out of the
rack for rear-panel and connector maintenance without removing the instrument
from the rack.
WARNING. To prevent the rackmounted instrument from tipping forward onto the
operator, install the instrument so that the operator will be able to access all of
its rear devices without pushing down on the instrument.
Verify that the rack does not become unstable with the instrument fully extended.
Do not leave the instrument extended when finished accessing the rear panel.
