Kit Description
6
TDS5000B Series (Option 1R) Rackmount Kit
The following environmental characteristics supercede those listed in the
specifications and performance verification sections of the manual for your
instrument.
Table 1: Warranted characteristics
Characteristic Description
Temperat ure, Insi de Rack Cabinet
Operating +10 _Cto+45_C(+50_Fto+113_F)
Non-operating --22 _Cto+60_C(--7.6_F to +140 _F)
Shock
Operating and Non-operating 20 g, 11 ms, half sine, each axis, 3 drops
each
Clearance Requirements
The rack in which the rack adapted instrument is mounted must provide the
following clearance requirements:
H A minimum of 10.5 inches (266.7 mm) of vertical space.
H A minimum width of 17 5/8 inches (448 mm) between the left- and
right-front rails in the rack.
H A minimum depth of 20 inches (508 mm).
CAUTION. Adhering to these clearance requirements provides the rack-mounted
instrument with sufficient clearance for air circulation and accommodation of
the power cord and mounting hardware. Failure to provide these clearances can
result in overheating and can cause instrument faults or failure.
Environmental
Requirements
