Tektronix TDS5104B Specification And Performance Verification Technical Reference

Specifications
1-10
TDS5000B Series Specifications and Performance Verification
Table 1- 2: Channel input and vertical specifications (Cont.)
Characteri sti c Description
Offset accuracy SCALE range Offs et range
1mV/divto9.95mV/div
±[(0.2% ×| net off set |) + 1.5 mV + (0.1 div
×V/div setting)]
10 mV/div to 99.5 mV/ div
±[(0.35% ×| net offs et |) + 1.5 mV + (0.1 div
×V/div setting)]
100 mV/div to 1.0 V/div
±[(0.35% ×| net offs et |) + 15 mV + (0.1 div
×V/div setting)]
1.01 V/div to 10 V/div
±[(0.25% ×| net offs et |) + 150 mV + (0.1 div
×V/div setting]
Temperatures >40 °C
±[(0.75% ×| net offs et |) + 150 mV + (0.1 div
×V/div setting)]
where, net offset = offset -- (position × volts/division)
DC gain accuracy, Sample or Average acquisi tion
mode
±1.5% + 1.0% × |net offset /offset range|
TDS5104B: ±3% + 1.0% × |net offset /offset range| for 2 mV/div --
3.98 mV/div
Refer to Offset Range specifications
