Tektronix TDS5104B

Specifications
TDS5000B Series Specifications and Performance Verification
1-11
Table 1- 2: Channel input and vertical specifications (Cont.)
Characteri sti c Description
DC voltage measurement accuracy Measurement type DC accuracy (in volts)
Sample acquisition mode,
typical
Any sample
±[(1.5% + 1.0% × |net offset /offset range|)×
|reading -- net offset| + offset accuracy + (0.13
div × V/div setting) + 0.6 mV]
TDS5104B: 2 mV/div -- 3.98 mV/div
±[(1.5% + 3.0% × |net offset /offset range|)×
|reading -- net offset| + offset accuracy + (0.13
div ×V/div setting) + 0.6 mV]
Delta voltage measurement
between any two points
acquired under the same
setup and ambient condi-
tions
±[(1.5% + 1.0% × |net offset /offset range|)×
|reading -- net offset| + (0.26 div × V/div
setting) + 1.2 mV]
TDS5104B: 2 mV/div -- 3.98 mV/div
±[(1.5% + 3.0% × |net offset /offset range|)×
|reading -- net offset| + (0.26 div ×V/div
setting) + 1.2 mV]
where, net offset = offset -- (position × volts/division)
n Average acquisition mode Average of ≥16 waveforms
±[(1.5% + 1.0% × |net offset /offset range|)×
|reading -- net offset| + offset accuracy
+0.06div× V/div]
TDS5104B: 2 mV/div -- 3.98 mV/div
±[(1.5% + 3.0% ×
|net offset /offset range|)× |reading -- net
offset| +
offset accuracy + (0.06 div × V/div)]
Delta voltage measurement
between any two averages
of ≥16 waveforms acquired
under the same setup and
ambient conditions
±[(1.5% + 1.0% × |net offset /offset range|)×
|reading -- net offset| + (0.1 div × V/div setting)
+0.3mV]
TDS5104B: 2 mV/div -- 3.98 mV/div
±[(1.5% + 3.0% × |net offset /offset range|)×
|reading -- net offset| + (0.1 div × V/div
+0.3mV)]
Where, net offset = offset -- (position × volts/division)
Nonlinearity, typical <1 LSB differential, <1 LSB integral, independently based
