Tektronix THDP0100 Installation And Safety Instructions

Standard Accessories
THDP0200 and TMDP0200 probe standard accessory derating table
Combined probe and accessory common-mode
voltage and input voltage-to-earth ratings
Accessory THDP0100
1
THDP0200 TMDP0200
Extender leads (196-3523-xx) 2300 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550 V CAT I
300 V CAT III
Handheld probes (TP175-FL) 1000 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550 V CAT I
300 V CAT III
Crocodile clips (344-0670-xx) 300 V CAT I 300 V CAT I 300 V CAT I
Pogo pin tip adapters and tips
(020-3107-xx)
150 V CAT II 150 V CAT II 150 V CAT II
Extended test probe adapters
(012-1724-xx)
300 V CAT I
300 V CAT II
300 V CAT II 300 V CAT I
300 V CAT II
Hook clips (AC280-FL) 1000 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550 V CAT I
300 V CAT III
Pincer clips (AC283-FL) 1000 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550 V CAT I
300 V CAT III
Alligator clips (AC285-FL) 1000 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550 V CAT I
300 V CAT II
1
The THDP0100 probe can be used with the THDP0200 and TMDP0200 accessories, but
only at the reduced voltage levels listed in this table.
