Installation Instructions
Mount the Inst
rument to the Shelf
The slide-out shelf permits the rack-adapted instrument to be extended out of the
rack for rear-panel and connector maintenance without removing the instrument
from the rack
.
The rackmount kit includes a mechanical safety stop that prevents the instrument
from accide
ntally being pulled out while probes are attached.
CAUTION. To prevent damaging the probes, remove any probes from the
instrument before extending the instrument. Also, for the TLA7012 Portable
Mainframe, you may want to remove any modules from the instrument to make it
lighter. Always reinstall the mechanical safety stop afte r you push the instrument
back into the rack.
WARNING. To prevent the rackmounted instrument from tipping forward onto the
operator, install the instrument so that the operator is able to access all of its rear
devices without pushing down on the instrument.
Verify that the rack does not become unstable with the instrument fully extended.
Do not leave the instrument extended when finished accessing the rear panel.
WARNING. To prevent the instrument from tipping or dropping onto the installers,
two or more people should install this instrument into the rack cabinet.
After completing the installation procedure, the installers should verify that the
instrument and rack c abinet will not tip forward while the instrument is in the
ext
ended position.
18 TLA6200, TLA6400, & TLA7012 Rackmount Kit Instructions
