Tektronix TLA7000 Series - Figure 21: Soft Power down Jumper Setting; Table 6: Mainframe Backplane Jumpers

Benchtop Mainframe Removal and Installation Procedures
32
TLA7000 Series Mainframe Technical Reference Manual
Before installing the backplane board in the mainframe verify the correct
position and location of the jumpers (refer to Figure 21 and to Table 6).
Install the backplane board following the removal procedures in reverse order.
Table 6: Mainframe backplane jumpers
Location Pins
JP1 No Jumper inst alled
JP2 pins 2--5
JP1
JP2
1
2
3
4
5
Figure 21: Soft power down jumper setting
