Tektronix WFM6120 Technical Reference

Incoming Inspection
18. Set the generat
or for embedded audio in 2 groups, starting with group 1, and
then access and set its audio channels:
a. Press Modules
and select DVG1.
b. Press Test S ignal s and select Module Parameters.
c. Select Audio and set the audio channels as follows:
Channel 1: 50 Hz, –35 dB
Channel 2: 100 Hz, –30 dB
Channel 3: 150 Hz, –25 dB
Channel 4
: 200 Hz, –20 dB
Channel 5: 250 Hz, –15 dB
Channel 6: 300 Hz, –10 dB
Channel 7: 400 Hz, –5 dB
Channel 8: 500 Hz, 0 dB
19. Connect the output of the DVG2 to the SDI A input of the instrument under
test.
20. Press and hold the Display Select button 4 to display the AUDIO pop-up
menu.
21. Select Audio Input > Embedded.
22. Pre
ss the AUDIO button.
23. Verify that the level meter bars have a stair step pattern from –35 dB on
ch
annel 1 to 0 dB on channel 8.
NOTE. If level-meter bars indicate that audio is not present, set the TG700 module
number of groups to 2 even if it appears to be set already.
24. Record Pass or Fail for Embedded Display in the test record.
25. Press and hold the Display Select button 4 to display the AUDIO pop-up
menu.
26. Select Phase Pair > 1 & 2.
27. Go through the other phase pairs (3 & 4, 5 & 6, 7 & 8) and verify that the
phase display changes in each one.
28. Record Pass or Fail for Embedded to Lissajous in the test record.
70 Waveform Monitors Specifications and Performance Verification
